beta/ X - The better pump choice for NZ industry

Key-visual-simplify beta X
Download Brochure

Why the beta/ X is the ideal choice

The beta/ X diaphragm metering pump combines efficiency, precision, and modern technology in a forward-thinking design. It offers exceptional reliability and sets new standards in metering technology—perfect for applications where quality and cost-effectiveness are paramount. With innovative technology, user-friendly operation, and an optimized design, the beta/ X excels with quick installation, intuitive commissioning, and effortless maintenance. At the same time, it reduces workload and effectively lowers operating costs, making it the ideal solution for precise and reliable metering.



Technology in detail

The Highlights of the beta/ X Diaphragm Metering Pump


betaX_display_ProMinent
Compact display and status monitoring

The small LCD display provides a clear overview, while the three all-round visible status LEDs ensure that operating, warning and error messages are always easily recognizable.

Precise Metering
With a wide setting range of 1:1,000 and a stepper motor, the pump ensures continuous dosing. The infinitely variable volume setting guarantees maximum precision.

Design-without-title
Flexible Control

External control is possible via a contact or an analog signal (0/4-20 mA), which enables versatile integration into various systems.

Space-Saving Installation
The innovative click base enables easy installation, either horizontally on the floor or vertically on the wall.

betaX_connectivity_ProMinent

Modern Communication

The service data can be conveniently read out and programmed via NFC and Bluetooth, enabling quick and intuitive configuration.

Optional Features

The pump is optionally available with a 230V/24V relay output (programmable NO/NC) and as a PFAS-free version.

The magic of simplicity

Key Features

of the beta/ X stepper motor pump

sub-visual-simply-easy

simply easy

Fast Dosing with Clickwheel
The beta/ X enables direct, intuitive dosing without calculations. Errors and time loss are minimized.

Easy Installation and Maintenance
The click system of the beta/ X allows for quick installation—either horizontally or vertically. Maintenance is hassle-free even in tight spaces.

Highly Visible 360-Degree Status LEDs
LEDs clearly display operational, warning, and error messages. This enhances safety and simplifies monitoring.


sub-visual-simply-connected

simply connected

Contactless communication
Device data can be read out and settings transferred quickly using NFC or Bluetooth.

Ready for remote access
The digital universal slot enables connection to monitoring systems for easy remote control.


Sub-visual-simply-reliable

simply reliable

Universally Applicable
The beta/ X covers a huge range from 10 ml/h to 50 l/h. Fewer variants simplify selection and reduce spare parts requirements.

Precise and Powerful
Optimized dosing heads deliver greater precision, stronger suction power, and improved air handling—ideal even for viscous media.

Efficient and Sustainable
Up to 50% less energy consumption compared to the previous model. The beta/ x pump is available in a PFAS-free version and is easy to recycle.


How-to videos

beta/ X- How to...

Areas of Application

The versatility of beta/ X:

  • beta X NZ (2)
  • beta X NZ
  • beta X NZ (3)
  • beta X nz
